Short Rail Solar Mounting
Short rail solar mounting for trapezoidal roof
Model:SPC-SR
Installation Site:Trapezoidal metal roof
Material: Al6005-T5 Aluminum
Tilt Angle: 0° to 60°
PV Module: Framed, Frameless
PV Orientation: Portrait, Landscape
Wind Load: 60 m/s
Snow Load: 1.4 KN/M2
Descriptions
Short Rail Solar Mounting is designed for trapezoidal tin roof, which can be directly installed on the roof without continues solar rail, saving cost. easy to install, widely used, It is suitable for large commercial and public solar systems, framed and frameless modules, and can be installed vertically or horizontally.
Short Rail Solar Mounting is made of high-quality AL6005-T5, without interfere with the surface of the roof and the products are strictly in accordance with the industry Standard processing, the total length of the guide rail is 400mm, and 24 holes are designed on both sides, which is easy to operate during installation.
An outstanding feature of Short Rail Solar Mounting for solar is its high availability, the design of the short guide rail greatly reduces the material cost, thanks to our innovative, Which can reduce the installation time to a minimum, the product is highly resistant to corrosion, which ensures a long service life of the guide rail, and offering the possibility of full recycling, the rails are specially designed for the installation of solar panels.
Features of the Short Rail Solar Mounting
- Easy Installation:
The innovative Short rail have greatly simplified the installation of PV modules. The System can be installed with a single Hexagon Key and standard tool it. The Solar Roof system is aided by a very high level of preassembly. The module and unique rail extension method greatly reduce installation time.
2.Great Flexibility:
With the Short Rail Solar Mounting, framed photovoltaic modules can be easily mounted on pitched roofs. The Solar Roof system has mounting accessories designed for application on almost every roof cladding available with unique rail .Excellent Compatibility. Designed as a universal racking system, framed modules from all the popular manufacturers can be used.
3.High Accuracy:
Without the need of onsite cutting, the use of our unique rail extending allows the system to be installed with millimeter accuracy.
- Excellent Adaptability:
The position adjustment of Short Rail Solar Mounting allows a level PV array to be established, no matter how uneven the roof is.
- Maximum Lifespan:
All components are made of quality extruded aluminum and stainless steel. The high corrosion resistance guarantees the maximum possible lifespan and is also completely recyclable.
OEM &ODM | both are welcomed |
components include:
- Slotted rails Mounting structure
- End and mid clamps
- Rubber gasket
- Nuts and bolts
Above components are made out of anodized aluminum
rails riveted to metal roof with self-drilling screws
Welcome to contact us anytime, our company website: www.solarpartscomponents.com
Datasheet | |
Short Rail Solar Mounting | |
Item type: | Short rail solar mounting for trapezoidal roof |
Type : | SPC-SR |
Installation Site : | Trapezoidal metal roof |
Installation Angle : | 0-60° |
Profile Material : | Al6005-T5 |
Fasten Parts : | SUS 304 / A2-70 Stainless Steel |
Small Components : | AL & Stainless Steel |
Color : | Silvery or according to customer requirements |
Wind Load : | 60 m / s ( 130 mph ) |
Snow Load : | 1.4 KN / M2 ( 30 psf ) |
PV Modules : | Frame, Frameless solar Module |
Module Orientation : | Portait and Landscape |
Warranty | 10 years |
Designed LifeSpan | 25 years |
Packing Details : | |
Inner : | Bubble bag+inner box+Carton |
Outer : | Wooden Box, Steel Pallet, MDF, etc |
